VPC (Virtual Private Cloud)


logo

Amazon VPC lets you provision a logically isolated section of the AWS Cloud where you can launch AWS resources in a virtual network that you define.

More Information

Key Concepts​

  • VPC: a virtual network dedicated to your AWS account, logically isolated from other virtual networks
  • Subnet: a range of IP addresses in your VPC
  • Route Table: a set of rules (routes) that determine where network traffic is directed
  • Internet Gateway: a gateway that enables communication between your VPC and the internet
  • NAT Gateway: a gateway that allows instances in a private subnet to connect to the internet while preventing the internet from initiating connections with those instances
More Information

Subnets​

  • A subnet resides in a single Availability Zone
  • A subnet can be public (traffic routed to an Internet Gateway) or private (no direct route to the internet)
  • Each subnet must be associated with a route table
  • AWS reserves the first four and the last IP address in each subnet CIDR block
More Information

Internet Gateway​

  • Horizontally scaled, redundant, and highly available
  • Allows communication between instances in a VPC and the internet
  • Only one Internet Gateway can be attached to a VPC at a time
  • Instances must have a public IP or Elastic IP to communicate through the Internet Gateway
More Information

NAT Gateway​

  • Enables instances in a private subnet to connect to the internet or other AWS services
  • Prevents the internet from initiating connections with those instances
  • Must be created in a public subnet
  • Must be associated with an Elastic IP address
  • Not supported for IPv6 traffic (use an egress-only Internet Gateway instead)
More Information

Route Tables​

  • Each VPC has a main route table that is automatically created
  • Each subnet must be associated with a route table (uses the main route table by default)
  • A route table contains a set of rules (routes) that determine where network traffic is directed
  • The most specific route that matches the traffic is used
More Information

Security Groups​

  • Act as a virtual firewall at the instance level
  • Control inbound and outbound traffic
  • Stateful: if an inbound rule allows traffic in, the response is automatically allowed out
  • By default, all inbound traffic is denied and all outbound traffic is allowed
  • You can specify allow rules but not deny rules
More Information

Network ACLs​

  • Act as a virtual firewall at the subnet level
  • Control inbound and outbound traffic for all instances in the associated subnet
  • Stateless: return traffic must be explicitly allowed by rules
  • Rules are evaluated in order, starting with the lowest numbered rule
  • You can specify both allow and deny rules
  • Each VPC has a default Network ACL that allows all inbound and outbound traffic
More Information

VPC Peering​

  • A networking connection between two VPCs that enables routing traffic between them using private IP addresses
  • Instances in either VPC can communicate as if they are within the same network
  • Can be created between VPCs in different accounts and different regions
  • CIDR blocks of peered VPCs cannot overlap
  • VPC peering is not transitive (VPC A peered with VPC B, and VPC B peered with VPC C, does not mean VPC A can communicate with VPC C)
More Information

VPC Flow Logs​

  • Capture information about the IP traffic going to and from network interfaces in a VPC
  • Can be created at three levels: VPC, subnet, or network interface
  • Flow log data can be published to Amazon CloudWatch Logs or Amazon S3
  • Useful for diagnosing security group rules, monitoring traffic, and troubleshooting connectivity issues
