ECR (Elastic Container Registry)


logo

Amazon ECR is a fully managed container image registry that makes it easy to store, manage, and deploy container images.

More Information

Key Concepts​

  • Registry: provided to each AWS account; you can create repositories in your registry and store images in them
  • Repository: contains a collection of container images (similar to a Docker Hub repository)
  • Image: a container image stored in a repository; identified by tag or digest
More Information

Repository Types​

Private Repository​

  • Images are accessible only within your account or to accounts and services you explicitly grant access
  • Access controlled via IAM and repository policies

Public Repository (ECR Public)​

  • Images are publicly available to anyone on the internet
  • Hosted on the ECR Public Gallery (gallery.ecr.aws)
More Information

Authentication​

  • Docker CLI must be authenticated to an ECR registry before pushing or pulling images
  • Authentication tokens are valid for 12 hours
  • Login command:
aws ecr get-login-password --region <region> | docker login --username AWS --password-stdin <account_id>.dkr.ecr.<region>.amazonaws.com
More Information

Image Lifecycle Policies​

  • Automate the cleanup of unused or old images
  • Rules can be based on image age or count
  • Helps reduce storage costs by removing images that are no longer needed
  • Rules are evaluated in priority order
More Information

Image Scanning​

  • Identifies software vulnerabilities in container images
  • Two scanning types:
    • Basic scanning: uses the Common Vulnerabilities and Exposures (CVE) database; can be triggered on push or manually
    • Enhanced scanning: uses Amazon Inspector for continuous and automated scanning
  • Scan findings are reported with severity levels
More Information

Cross-Region and Cross-Account Replication​

  • Automatically replicate images across regions and accounts
  • Configured at the registry level with replication rules
  • Useful for multi-region deployments and disaster recovery
More Information

Encryption​

  • Images are encrypted at rest by default using Amazon S3-managed encryption keys
  • Optionally, you can use AWS KMS keys for encryption
More Information
